| Colours | pearl black / green |
|---|---|
| Frame | ALU NEW WM SHAPE ICR 6061 |
| Fork | SR SUNTOUR XCR AIR 100 RLO |
| Chainring | SHIMANO FC-MT510-1 12SPD 30T |
| Shifting | SHIMANO DEORE SL-M6100 1x12SPD |
| Derailleur | SHIMANO DEORE RD-M6100 12SPD |
| Front derailleur | *** |
| Freewheel | SHIMANO DEORE CS-M6100 12SPD 10-51T |
| Chain | SHIMANO CN-M6100 12SPD |
| Brakes | SHIMANO BR-MT201 |
| Brake levers | SHIMANO BL-MT201 |
| Front hub | HB-TX505 |
| Rear hub | FH-QC500 |
| Rims | MACH1 3.90 SL Superlight |
| Tires | SCHWALBE Racing Ralph |
| Pedals | UNION SP-600 |
| Handlebars | 4EX sand blasted 700mm |
| Stem | 4EX sand blasted |
| Seatpost | 4EX sand blasted |
| Saddle | SELLE ROYAL |
| Bottom bracket | Integrated |
| Weight | 12.6 |
| Frame size | 15,5" |
|---|---|
| Minimum height (cm) | 150 |
| Maximum height (cm) | 165 |
| Seat tube (mm) (A) | 394 |
| Top tube (mm) (B) | 580 |
| Chainstay (mm) (C) | 442 |
| Wheelbase (mm) (D) | 1073 |
| Seat tube angle (°) (E) | 72.5 |
| Head tube angle (°) (F) | 70 |
| Reach (mm) (E) | 386 |
| Stack (mm) (F) | 616 |
| BB drop (mm) | 60 |
